aluminum-plastic composite tape

Single-sided aluminum foil is a kind of aluminum foil Mylar, also known as aluminum-plastic composite tape. The soft calendered aluminum foil and polyester film are used as raw materials, and the dry gravure is used for compounding. After the aluminum foil Mylar film is matured, it will be slit and rolled. One side is aluminum foil, the other side is Mylar, which has the function of insulation on one side and conduction on the other.



aluminum-plastic composite tape is mainly used for interference shielding of communication cables. It can also be used with coated sensitive adhesive. The die-cut aluminum foil Mylar film is mostly used for grounding assembly of electronic products.

The common specifications of aluminum-plastic composite tape are as follows:
Thickness 20u (0.022mm) structure: aluminum foil 7u/polyester film 12u
Thickness 25u (0.025mm) structure: aluminum foil 10u/polyester film 12u
Thickness 38u (0.038mm) structure: aluminum foil 10u/polyester film 25u
Thickness 50u (0.053mm) structure: aluminum foil 25u/polyester film 25u
