1100 series aluminium foil

Product introduction
1100 aluminium foil has good formability, corrosion resistance, thermal conductivity and a certain strength. It is widely used in the heat exchanger of refrigeration industry, chemical and food industry storage containers , and the capacitor shell materials in the electronics industryetc.

Signi Aluminium stocks a variety of aluminium foil grades and sizes tailored to your needs and specifications.

Send us email

Specification

Performance

Application

1100 aluminium foil Technical Parameters

Alloy	1100 aluminium foil
Temper	H18、O、H22、H24,H26
Thickness（mm）	0.018-0.2
Width（mm）	100-1600
Length（mm）	C
Typical products	Electronic components, Fin stock,food packaging, drug packaging, etc.

Chemical Composition of 1100 aluminium foil：

Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others		Al
								Individual	Total
Si+Fe 0.95		0.05- 0.20	0.05	-	-	0.10	-	0.05	0.15	99.00

Mechanical propertiesof 1100 aluminium foil：

Alloy	Temper	Thickness (mm)	Tensile Strength （Mpa）	Yield Strength （Mpa）	Elongation (%)	Cupping test value I.E/mm
1100	O	0.08-0.10	80-110	≥50	≥18	≥6.0
	O	0.10-0.20	80-110	≥50	≥20	≥6.5
	H22	0.08-0.10	100-130	≥60	≥18	≥5.5
	H22	0.10-0.20	100-130	≥60	≥20	≥6.0
	H24	0.08-0.10	115-145	≥70	≥15	≥5.0
	H24	0.10-0.20	115-145	≥70	≥18	≥5.5
	H26	0.08-0.10	130-160	≥90	≥8	≥4.0
	H26	0.10-0.20	130-160	≥90	≥10	≥4.5
	H18	0.08-0.20	≥160	-	≥1	-

Typical Usage of 1100 aluminium foil：
It is widely used in the heat exchanger of refrigeration industry, chemical and food industry storage containers , and the capacitor shell materials in the electronics industry etc.
