Aluminium foil for flexible air duct

Aluminium foil for flexible air duct materia is formed by 8011 H0 Aluminium foil for flexible air duct continuous and tight clamping of screw. Owing to the oxidation nature of aluminium material, a layer of glue is usually coated during production to isolate the oxidation reaction between aluminium material and oxygen in the air. Aluminum foil duct is mainly used for ventilation in the terminal stage of fresh air system. The size of the product can be customized and the direction of the aluminium tube can be determined according to the actual needs. Ideal partners for fresh air dryers, lampblack pumps and general ventilation equipment. The maximum length can be obtained by stretching from the middle of the hard pipe to both ends. Normal service rating temperature - 70 C to 250 C.

Aluminium foil for flexible air duct specifications
Alloy: 8011 H0

Thickness: 0.1mm
Width: 60mm
Internal diameter: 72 mm



Aluminium foil for flexible air duct mechanical properties
Tensile strength Rm(Mpa):125~165
Yield strength Rp 0.2 (Mpa):110
Elongation%:2%~5%
Melting point (?): 650 (?)

Aluminium foil for flexible air duct packing:
